Altingoz - Laboratory Furnaces

We have been manufacturing high temperature labratory furnaces with working temperature up to 1700 °C, especially used for universities and industrial corporates research center, quality control labratories, agricultural researches, medical researches, process controlls and various calibration tests and selling in domestic and international markets.

Models above are our standard models, we can design and produce labratory furnaces according to customer needs. If you need to buy a custom size labratory furnace, please specify your furnace sizes(width-length-depth), working temperature. Send us an email to @

Laboratory Furnace Manufacturing

We can design and produce labratory furnaces according to customer needs.

Laboratory Applications

Sementation
Normalisation
Hardening
Tempering
Annealing
Aging
Stress Relief
Softhening
Surface Hardening

Materilas We Are Using for Laboratory Furnace

Resistance Wire
Controller
Thermocouple
Door
Insulation Material
Power Controller
Max Temperature
Working Temperature

Kanthall A1, SiO2, MoSi2
Digital PID 7 step programmable, PID-Thyristor
NiCr-Ni, PtRh%10-Pt., PtRh%13-Pt.
Opening to right or left
Refractory brick + Ceramic Blanket
SSR
1260ºC-1450ºC-1700ºC
1260ºC-1450ºC-1700ºC

Laboratory Furnace Sizes and Technical Specifications

Model	Sizes(cm)			Volume (dm³)	Max. Temperature (°C)	Resistance Wire Type	Controller Type	Measurement Type	Power (kw)	Supply Voltage (V)
Model	Width	Depth	Height	Volume (dm³)	Max. Temperature (°C)	Resistance Wire Type	Controller Type	Measurement Type	Power (kw)	Supply Voltage (V)
HT49	35	35	40	49	1.260	KanthalA1	PID-SSR	NiCr-Ni Tc	4,0	220
					1.450	SiO₂	PID-SSR	PtRh%10-Pt	11,0	380
					1.700	MoSi₂	PID-Thyristor Current Cont	PtRh%13-Pt	15,0	380
HT80	40	40	50	80	1.260	KanthalA1	PID-SSR	NiCr-Ni Tc	6,0	220
					1.450	SiO₂	PID-SSR	PtRh%10-Pt	14,0	380
					1.700	MoSi₂ ₁₈₀₀	PID-Thyristor Current Cont	PtRh%13-Pt	22,0	380
HT150	50	50	60	150	1.260	KanthalA1	PID-SSR	NiCr-Ni Tc	9,0	380
					1.500	MoSi₂ ₁₇₀₀	PID-Thyristor Current Cont	PtRh%10-Pt	20,0	380
					1.700	MoSi₂ ₁₈₀₀	PID-Thyristor Current Cont	PtRh%13-Pt	28,0	380
HT200	50	50	80	200	1.260	KanthalA1	PID-SSR	NiCr-Ni Tc	12,0	380
					1.500	MoSi₂ ₁₇₀₀	PID-Thyristor Current Cont	PtRh%10-Pt	23,0	380
					1.700	MoSi₂ ₁₈₀₀	PID-Thyristor Curret Cont	PtRh%13-Pt	32,5	380
HT240	50	60	80	240	1.260	KanthalA1	PID-SSR	NiCr-Ni Tc	15,0	380
					1.500	MoSi₂ ₁₇₀₀	PID-Thyristor Current Cont	PtRh%10-Pt	26,0	380
					1.700	MoSi₂ ₁₈₀₀	PID-Thyristor Current Cont	PtRh%13-Pt	37,0	380
HT300	50	60	100	300	1.260	KanthalA1	PID-SSR	NiCr-Ni Tc	21,0	380
					1.500	MoSi₂ ₁₇₀₀	PID-Thyristor Current Cont	PtRh%10-Pt	30,0	380
					1.700	MoSi2	PID-Thyristor Current Cont	PtRh%13-Pt	42,0	380
